Description

Description

SPECS

• Cutting space — 50 inches by 100 inches
• Speed guide 25-millimeter linear rails
• 3:1 planetary gearboxes
• Rack and pinion
• Homing/auto-squaring switches
• Mini-PC with 32-gigabyte SSD, monitor, mouse, and keyboard
• 500-watt smart power controller with fault detection and shut down
• High-speed DTHC5 torch-height control with isolated remote sensor module
• Four (4) 620 ounce-inch stepper motors
• Quality, U.S.-made microstepping motor drivers from Geckodrive
• Pre-loaded Linux computer and CommandCNC
• Fully licensed SheetCam and Control
• 3 by 3 by 11 gauge square tube with fully welded frame and gantry
• Powder-coated frame and gantry
• 4-inch water bed with drain

FEATURES

• Z-axis with rigid rail and ball screw
• Collision detection torch mount
• Ohmic sensing
• Backup touch off
• Digital torch-height control
• Dual-drive motors
• Cut or corrugated HVAC material
• Preloaded with Hypertherm tool charts
• Rapid travel speed of 600 inches per minute
• Cutting speeds match every book spec by Hypertherm and more
• Compatible with routers, plate markers, and oxy-fuel torches
• Computer station
• Two-year warranty
• Lifetime tech support

PLEASE CALL FOR PRICING, OPTIONAL FEATURES, SHIPPING QUOTES AND ESTIMATED LEAD TIMES. (915) 313-9333 ext 11.
